Descriere
Bobina de inductanta Linie/Motor, 2 Mh, 16 A, 3 Faze, 75 W, pentru Variator de viteza
Documente
Specificatii
Model/type | |
Number of poles, primary side | 3 |
Electrical | |
Max. rated current (Ith) at rated voltage DC | - |
Max. rated operation voltage Ue | 690 V |
Rated current AC | 17 A |
Relative short circuit voltage | - |
Other | |
Rated clock frequency | - |
Rated operating frequency | 50 Hz |
Resonance frequency | - |
Rated inductance | 2 mH |
Application | |
Suitable as output reactance coil | Yes |
Suitable as commutation reactance coil | No |
Suitable as net reactance coil | Yes |
Suitable as interference suppression reactance coil | No |
Suitable as ripple filter choke | No |
Protection | |
Degree of protection (IP) | IP00 |
Degree of protection (NEMA) | - |
Package 1 | |
volume | 11400 cm3 |
weight | 3,935 kg |
length | 25 cm |
width | 24 cm |
qmax | 1 |
qmin | 1 |
um | C62 |
gtin | 3389118066038 |
Package 2 | |
volume | 360000 cm3 |
weight | 83,83 kg |
length | 80 cm |
width | 60 cm |
qmax | 18 |
qmin | 18 |
um | PF |
gtin | 73389118066037 |
