Specificatii
| Model/type | |
| With light source | No |
| Type of control element | Short rotary handle |
| With front ring | Yes |
| Options | |
| Spring-return | No |
| Switching function latching | Yes |
| Colour | |
| Colour front ring | Black |
| Colour button | Black |
| Connection | |
| Type of electric connection | Screw connection |
| Number of contacts as normally open contact | 1 |
| Number of contacts as change-over contact | 0 |
| Number of contacts as normally closed contact | 0 |
| Setting/control | |
| Number of switch positions | 2 |
| Electrical | |
| Supply voltage | 230 V |
| Material | |
| Material front ring | Plastic |
| Measurements | |
| Hole diameter | 22.5 mm |
| Width opening | - |
| Height opening | - |
| Application | |
| Suitable for lighting | No |
| Protection | |
| Degree of protection (IP) | IP67/IP69K |
| Degree of protection (NEMA) | 13 |
| Package 1 | |
| volume | 181,818 cm3 |
| weight | 43 g |
| length | 9,1 cm |
| width | 5,4 cm |
| qmax | 1 |
| qmin | 1 |
| um | C62 |
| gtin | 3389110903447 |
| Package 2 | |
| volume | 792,88 cm3 |
| weight | 217 g |
| length | 26,5 cm |
| width | 8,8 cm |
| qmax | 5 |
| qmin | 5 |
| um | BX |
| gtin | 53389110903442 |
| Package 3 | |
| volume | 36000 cm3 |
| weight | 6,895 kg |
| length | 40 cm |
| width | 30 cm |
| qmax | 150 |
| qmin | 150 |
| um | CT |
| gtin | 43389110903445 |
| Package 4 | |
| weight | 64,604 kg |
| length | 80 cm |
| width | 60 cm |
| qmax | 1200 |
| qmin | 1200 |
| um | PF |
