Specificatii
| Other | |
| Rated operating frequency | 50 Hz |
| Rated clock frequency | 10 kHz |
| Application | |
| Suitable as sinus filter | No |
| Suitable as radio interference suppression filter | No |
| Suitable as audio frequency blockage | No |
| Suitable as du/dt-filter | No |
| Electrical | |
| Rated current AC | 2.2 A |
| Max. rated operation voltage Ue | 480 V |
| Max. rated current (Ith) at rated voltage DC | - |
| Protection | |
| Degree of protection (IP) | Other |
| Degree of protection (NEMA) | - |
| Model/type | |
| Number of poles, primary side | 3 |
| Package 1 | |
| volume | 8570,38 cm3 |
| weight | 3,328 kg |
| length | 18,2 cm |
| width | 27,7 cm |
| qmax | 1 |
| qmin | 1 |
| um | C62 |
| gtin | 3606485435794 |
| Package 2 | |
| volume | 360000 cm3 |
| weight | 92,872 kg |
| length | 80 cm |
| width | 60 cm |
| qmax | 24 |
| qmin | 24 |
| um | PF |
| gtin | 73606485435793 |
