Descriere
Noua Unica, Doza montaj incastrat standard italian 4m
Documente
Specificatii
| Model/type | |
| Equipped with | None |
| Model | Other |
| With screening | No |
| Transparent cover | - |
| Number of included spouts | 1 |
| Cover model | - |
| Construction type | Built-in installation box (device box) |
| Number of poles of the clamp | - |
| Shape | Rectangular |
| With screws | No |
| With nail lugs | No |
| Material | |
| Surface protection | Untreated |
| Material | Plastic |
| Halogen free | Yes |
| Options | |
| Couplable | No |
| Housing feed-through by seal membrane | No |
| Housing feed-through by nozzle | No |
| Housing feed-through by step membrane | No |
| Clamp position fixed | - |
| Pipe locking optional | No |
| Air tight | No |
| Sealable | No |
| Pipe locking | No |
| Housing feed-through by break-out opening | Yes |
| Provided with revolving ring | No |
| Measurements | |
| Diameter | - |
| Suitable for cable diameter | - |
| For tube diameter | 20/25 mm |
| Inner depth | 40 mm |
| Length | 131 mm |
| Width | 74 mm |
| Depth | 49 mm |
| Suitable for wall/board thickness | - |
| Connection | |
| Inlet from the rear | Yes |
| Number of inlets | 10 |
| Max. conductor cross section | 25 mm² |
| Protection | |
| Degree of protection (IP) | IP20 |
| Circuit integrity | None |
| Degree of protection (NEMA) | - |
| Mounting/installation | |
| Mounting switching equipment | Screwing |
| Luminaire hook mounting | No |
| Mounting method | Flush-mounted |
| Colour | |
| Colour | Yellow |
| Application | |
| Special application | Other |
| Other | |
| Cover attachment | - |
| For number of device inserts | - |
| Nozzle | None |
| Package 1 | |
| volume | 487,5 cm3 |
| weight | 40 g |
| length | 13 cm |
| width | 7,5 cm |
| qmax | 1 |
| qmin | 1 |
| um | C62 |
| gtin | 8420375122947 |
| Package 2 | |
| volume | 3920,625 cm3 |
| weight | 301 g |
| length | 22,5 cm |
| width | 20,5 cm |
| qmax | 5 |
| qmin | 5 |
| um | BX |
| gtin | 28420375122941 |
| Package 3 | |
| volume | 36000 cm3 |
| weight | 1,914 kg |
| length | 40 cm |
| width | 30 cm |
| qmax | 25 |
| qmin | 25 |
| um | CT |
| gtin | 38420375122948 |
