Specificatii
Connection | |
Type of connector | RJ45 8(8) |
Connection type | Insulation displacement connector |
Separate earthing connection | No |
Suitable for number of connectors | 1 |
Model/type | |
Mounting method shielding connection | Clip |
Number of modules (module system) | 2 |
With terminal resistor | No |
With label space | Yes |
With dust cover | Yes |
Assembly arrangement | Modular device for domestic switching devices |
With buses/couplings | Yes |
Measurements | |
Device depth | 40.5 mm |
Device width | 45 mm |
Device height | 45 mm |
Options | |
Mechanical coding | No |
Shielded buses | Yes |
Shielded housing | Yes |
Compatible with third-party covers | Yes |
Separate strain relief | Yes |
Colour | |
RAL-number | 9003 |
Colour | White |
Colour coding | Yes |
Protection | |
Degree of protection (IP) | IP20 |
Mounting/installation | |
Duct installation | No |
Type of fastening | Engage (snap) |
Floor box/subfloor mounted | No |
Flush-mounted installation | Yes |
Surface mounting | No |
Other | |
Category | 6 |
Outlet direction | Straight |
Package 1 | |
volume | 81 cm3 |
weight | 45 g |
length | 4,5 cm |
width | 4,5 cm |
qmax | 1 |
qmin | 1 |
um | C62 |
gtin | 3606489467449 |
Package 2 | |
volume | 2002 cm3 |
weight | 517 g |
length | 26 cm |
width | 14 cm |
qmax | 10 |
qmin | 10 |
um | BX |
gtin | 13606489467446 |
Package 3 | |
volume | 36000 cm3 |
weight | 5,6 kg |
length | 40 cm |
width | 30 cm |
qmax | 100 |
qmin | 100 |
um | CT |
gtin | 43606489467447 |
