Descriere
Optional accessories for circuit-breaker series NZM offers a comprehensive portfolio of application possibilities for worldwide use. Modular functional groups make mounting flexible and simple.
Documente
Specificatii
| Electrical | |
| Rated control supply voltage AC 50 Hz | 24 |
| Rated control supply voltage AC 60 Hz | 24 |
| Rated control supply voltage DC | 12 |
| Voltage type for actuating | AC/DC |
| End value adjustment range undelayed short-circuit release | 0 |
| Power consumption | - |
| Setting/control | |
| Initial value of the undelayed short-circuit release - setting range | 0 |
| Connection | |
| Type of electric connection | Screw connection |
| Number of contacts as normally open contact | 0 |
| Number of contacts as normally closed contact | 0 |
| Number of contacts as change-over contact | 0 |
| Application | |
| Suitable for power circuit breaker | No |
| Suitable for off-load switch | Yes |
| Suitable for motor safety switch | No |
| Suitable for overload relay | No |
| Package 1 | |
| volume | 0,000341 |
| weight | 0,077 |
| length | 0,07 |
| width | 0,075 |
| qmax | 1 |
| qmin | 1 |
| um | CS |
| gtin | 4015082597085 |
| Dimensions of product | |
| Volume | 0,00007814 |
| Weight | 0,074 |
| Length | 0,037 |
| Width | 0,032 |
| Depth | 0,066 |
