| Communication |
| Supporting protocol for SERCOS |
No |
| Number of interfaces PROFINET |
0 |
| Number of HW-interfaces parallel |
0 |
| Number of HW-interfaces other |
2 |
| Number of HW-interfaces serial TTY |
0 |
| Number of HW-interfaces USB |
0 |
| With optical interface |
No |
| Number of HW-interfaces wireless |
0 |
| Supporting protocol for INTERBUS-Safety |
No |
| Supporting protocol for AS-Interface Safety at Work |
No |
| Supporting protocol for DeviceNet Safety |
No |
| Supporting protocol for EtherNet/IP |
No |
| Supporting protocol for Foundation Fieldbus |
No |
| Supporting protocol for SafetyBUS p |
No |
| Supporting protocol for PROFINET CBA |
No |
| Supporting protocol for PROFINET IO |
No |
| Supporting protocol for PROFIsafe |
No |
| Supporting protocol for ASI |
No |
| Supporting protocol for PROFIBUS |
No |
| Supporting protocol for TCP/IP |
No |
| Supporting protocol for KNX |
No |
| Supporting protocol for CAN |
No |
| Supporting protocol for INTERBUS |
Yes |
| Supporting protocol for DeviceNet |
No |
| Supporting protocol for Modbus |
No |
| Supporting protocol for Data-Highway |
No |
| Supporting protocol for LON |
No |
| Supporting protocol for other bus systems |
No |
| Supporting protocol for SUCONET |
No |
| Number of HW-interfaces RS-422 |
0 |
| Number of HW-interfaces RS-485 |
0 |
| Number of HW-interfaces industrial Ethernet |
0 |
| Number of HW-interfaces RS-232 |
0 |
| Approval/certification |
| SIL according to IEC 61508 |
None |
| Performance |
| Transmission rate |
500 kBit/s |
| Performance level according to EN ISO 13849-1 |
None |
| Model/type |
| With potential separation |
Yes |
| Type of data transmission |
Module rack extension |
| Options |
| Radio standard GPRS |
No |
| Redundancy |
No |
| Radio standard GSM |
No |
| Mobile communications standard 3G (UMTS) |
No |
| Radio standard Bluetooth |
No |
| Radio standard WLAN 802.11 |
No |
| IO link master |
No |
| Measurements |
| Height |
56 mm |
| Width |
178 mm |
| Depth |
259 mm |
| Protection |
| Explosion safety category for dust |
None |
| Explosion safety category for gas |
None |
| Other |
| Appendant operation agent (Ex ia) |
No |
| Appendant operation agent (Ex ib) |
No |
| Application |
| Suitable for safety functions |
No |
| Package 1 |
| volume |
2588,3 cm3 |
| weight |
195 g |
| length |
26 cm |
| width |
18,1 cm |
| qmax |
1 |
| qmin |
1 |
| um |
C62 |
| gtin |
3595862060721 |
| Package 2 |
| volume |
36000 cm3 |
| weight |
2,048 kg |
| length |
40 cm |
| width |
30 cm |
| qmax |
8 |
| qmin |
8 |
| um |
CT |
| gtin |
23595862060725 |
