| Application |
| Suitable for single-axis positioning |
No |
| Suitable for single-axis controller |
No |
| Suitable for multi-axis positioning |
No |
| Suitable for counting |
No |
| Suitable for weighing |
No |
| Suitable for temperature control |
No |
| Suitable for NC |
No |
| Suitable for SSI |
No |
| Suitable for welding control |
No |
| Suitable for pressure control |
No |
| Suitable for incremental data detection |
No |
| Suitable for safety functions |
Yes |
| Suitable for electronic positioning |
No |
| Suitable for CNC |
No |
| Suitable for detection absolute value |
No |
| Suitable for flux controller |
No |
| Suitable for flux measurement |
No |
| Suitable for flying saw |
No |
| Suitable for multi-axis control |
No |
| Suitable for path controller |
No |
| Suitable for cam controller |
No |
| Communication |
| Supporting protocol for SERCOS |
No |
| Number of interfaces PROFINET |
0 |
| Number of HW-interfaces parallel |
0 |
| Number of HW-interfaces other |
2 |
| Number of HW-interfaces serial TTY |
0 |
| Number of HW-interfaces USB |
0 |
| With optical interface |
No |
| Number of HW-interfaces wireless |
0 |
| Supporting protocol for INTERBUS-Safety |
No |
| Supporting protocol for AS-Interface Safety at Work |
No |
| Supporting protocol for DeviceNet Safety |
No |
| Supporting protocol for EtherNet/IP |
No |
| Supporting protocol for Foundation Fieldbus |
No |
| Supporting protocol for SafetyBUS p |
No |
| Supporting protocol for PROFINET CBA |
No |
| Supporting protocol for PROFINET IO |
No |
| Supporting protocol for PROFIsafe |
No |
| Supporting protocol for ASI |
No |
| Supporting protocol for PROFIBUS |
No |
| Supporting protocol for TCP/IP |
No |
| Supporting protocol for KNX |
No |
| Supporting protocol for CAN |
No |
| Supporting protocol for INTERBUS |
No |
| Supporting protocol for DeviceNet |
No |
| Supporting protocol for Modbus |
No |
| Supporting protocol for Data-Highway |
No |
| Supporting protocol for LON |
No |
| Supporting protocol for other bus systems |
Yes |
| Supporting protocol for SUCONET |
No |
| Number of HW-interfaces RS-422 |
0 |
| Number of HW-interfaces RS-485 |
0 |
| Number of HW-interfaces industrial Ethernet |
0 |
| Number of HW-interfaces RS-232 |
0 |
| Approval/certification |
| SIL according to IEC 61508 |
2 |
| Options |
| Frequency measurement |
No |
| System accessory |
Yes |
| Radio standard GPRS |
No |
| Radio standard GSM |
No |
| Mobile communications standard 3G (UMTS) |
No |
| Function block automatic reset |
No |
| Number of functions |
1 |
| Radio standard Bluetooth |
No |
| Function block emergency stop |
No |
| Radio standard WLAN 802.11 |
No |
| Function block restart blockage |
No |
| Function block affirm push button |
No |
| IO link master |
No |
| Function block operating mode selection |
No |
| Function block 2-hand switching |
No |
| Rack-assembly possible |
No |
| Performance |
| Performance level according to EN ISO 13849-1 |
Level d |
| Connection |
| Fieldbus connection over separate bus coupler possible |
Yes |
| Measurements |
| Height |
118 mm |
| Width |
25 mm |
| Depth |
114 mm |
| Protection |
| Explosion safety category for dust |
None |
| Explosion safety category for gas |
None |
| Degree of protection (IP) |
IP20 |
| Degree of protection (NEMA) |
- |
| Electrical |
| Voltage type (supply voltage) |
DC |
| Supply voltage AC 50 Hz |
- |
| Supply voltage AC 60 Hz |
- |
| Supply voltage DC |
20.4 V |
| Model/type |
| Function block contactless working protection installation |
No |
| Other |
| Appendant operation agent (Ex ia) |
No |
| Appendant operation agent (Ex ib) |
No |
| Setting/control |
| Function block access control |
No |
| Contactor control function block |
Yes |
| Mounting/installation |
| Front built-in possible |
No |
| Suitable for rail mounting |
Yes |
| Wall mounting/direct mounting |
No |
| Package 1 |
| volume |
1360,125 cm3 |
| weight |
270 g |
| length |
15,5 cm |
| width |
13,5 cm |
| qmax |
1 |
| qmin |
1 |
| um |
C62 |
| gtin |
3606489832872 |
| Package 2 |
| volume |
36000 cm3 |
| weight |
5,019 kg |
| length |
40 cm |
| width |
30 cm |
| qmax |
16 |
| qmin |
16 |
| um |
CT |
| gtin |
43606489832870 |
