Specificatii
| Electrical | |
| Integrated short-circuit protection selective to fuse gG | 0 A |
| Nominal discharge surge current (8/20) | 40 kA |
| Voltage protection level L-N | 1.56 kV |
| Voltage protection level | 2.4 kV |
| Number of conductors (without earthing) | 1 |
| Max. continuous voltage DC | 0 V |
| Nominal voltage DC | 0 V |
| Nominal voltage AC | 1000 V |
| Max. overcurrent protection device, series connection (fuse) | 0 A |
| Max. overcurrent protection device, parallel connection (fuse) | 0 A |
| Max. discharge surge current (8/20) | 40 kA |
| Max. PV-voltage | 0 V |
| Voltage protection level N-PE | 1 kV |
| Max. continuous voltage AC | 1560 V |
| Short-circuit breaking capacity (Isccr) | 40 kA |
| Protection | |
| Integrated short-circuit protection | Yes |
| Degree of protection (IP) | Other |
| Options | |
| System configuration TN-C | No |
| Leakage-current free | No |
| System configuration DC | No |
| System configuration TN | No |
| System configuration IT | Yes |
| System configuration TT | No |
| System configuration TN-S | No |
| System configuration TN-C-S | No |
| System configuration other | No |
| Other | |
| Signalling at the device | Optical |
| Connection | |
| Max. conductor cross section solid (solid, stranded) | 150 mm² |
| Max. conductor cross section flexible (fine-strand) | 150 mm² |
| Mounting/installation | |
| Mounting method | On basic element |
| Measurements | |
| Construction size | Other |
| Communication | |
| With remote signalling contact | No |
| Model/type | |
| Integrated backup fuse | No |
| Category type 2 | No |
| Package 1 | |
| volume | 1955 cm3 |
| weight | 690 g |
| length | 17 cm |
| width | 11,5 cm |
| qmax | 1 |
| qmin | 1 |
| um | C62 |
| gtin | 3303430501831 |
| Package 2 | |
| volume | 72000 cm3 |
| weight | 11,7 kg |
| length | 60 cm |
| width | 40 cm |
| qmax | 16 |
| qmin | 16 |
| um | CT |
| gtin | 43303430501839 |
