Descriere
Pornire motor directa SIL, TeSys Island, 40A AC-1, 38A AC-3, 18.5kW / 20hp
Documente
Specificatii
| Connection | |
| Number of inputs | 1 |
| Number of motor outlets | 1 |
| Fieldbus connection over separate bus coupler possible | Yes |
| Type of electric connection | Plug-in connection |
| Short-circuit protection, outputs available | No |
| Type of electrical connection at the motor output | Screw connection |
| Communication | |
| Supporting protocol for SERCOS | No |
| Number of HW-interfaces parallel | 0 |
| Number of interfaces PROFINET | 0 |
| Number of HW-interfaces other | 2 |
| Number of HW-interfaces serial TTY | 0 |
| Number of HW-interfaces USB | 0 |
| With optical interface | No |
| Number of HW-interfaces wireless | 0 |
| Supporting protocol for INTERBUS-Safety | No |
| Supporting protocol for AS-Interface Safety at Work | No |
| Supporting protocol for DeviceNet Safety | No |
| Supporting protocol for EtherNet/IP | No |
| Supporting protocol for Foundation Fieldbus | No |
| Supporting protocol for SafetyBUS p | No |
| Supporting protocol for PROFINET CBA | No |
| Supporting protocol for PROFINET IO | No |
| Supporting protocol for PROFIsafe | No |
| Supporting protocol for ASI | No |
| Supporting protocol for PROFIBUS | No |
| Supporting protocol for TCP/IP | No |
| Supporting protocol for KNX | No |
| Supporting protocol for CAN | No |
| Supporting protocol for INTERBUS | No |
| Supporting protocol for DeviceNet | No |
| Supporting protocol for Modbus | No |
| Supporting protocol for Data-Highway | No |
| Supporting protocol for LON | No |
| Supporting protocol for other bus systems | Yes |
| Supporting protocol for SUCONET | No |
| Number of HW-interfaces RS-422 | 0 |
| Number of HW-interfaces RS-485 | 0 |
| Number of HW-interfaces industrial Ethernet | 0 |
| Number of HW-interfaces RS-232 | 0 |
| Model/type | |
| With brake output | No |
| With thermal motor protection | Yes |
| Type of digital output | None |
| Approval/certification | |
| SIL according to IEC 61508 | 2 |
| Options | |
| System accessory | Yes |
| Radio standard GPRS | No |
| Radio standard GSM | No |
| Mobile communications standard 3G (UMTS) | No |
| Radio standard Bluetooth | No |
| Radio standard WLAN 802.11 | No |
| IO link master | No |
| Rack-assembly possible | No |
| Electrical | |
| Permitted voltage at output | 0 V |
| Permitted voltage at input | 0 V |
| Type of voltage (input voltage) | AC |
| With motor current parameter setting | No |
| Rated operation current of the motor | 0.76 A |
| Voltage type (supply voltage) | DC |
| Supply voltage AC 50 Hz | - |
| Supply voltage AC 60 Hz | - |
| Type of output voltage | AC |
| Supply voltage DC | 20.4 V |
| Performance | |
| Performance level according to EN ISO 13849-1 | Level d |
| Measurements | |
| Height | 121 mm |
| Width | 45 mm |
| Depth | 115 mm |
| Protection | |
| Explosion safety category for dust | None |
| Explosion safety category for gas | None |
| Degree of protection (IP) | IP20 |
| Degree of protection (NEMA) | - |
| Other | |
| Appendant operation agent (Ex ia) | No |
| Appendant operation agent (Ex ib) | No |
| Mounting/installation | |
| Front built-in possible | No |
| Suitable for rail mounting | Yes |
| Wall mounting/direct mounting | No |
| Application | |
| Suitable for safety functions | Yes |
| Package 1 | |
| volume | 893,75 cm3 |
| weight | 772 g |
| length | 13 cm |
| width | 12,5 cm |
| qmax | 1 |
| qmin | 1 |
| um | C62 |
| gtin | 3606489832810 |
| Package 2 | |
| volume | 18000 cm3 |
| weight | 11,109 kg |
| length | 40 cm |
| width | 30 cm |
| qmax | 14 |
| qmin | 14 |
| um | CT |
| gtin | 13606489832817 |
