Descriere
Unitate de declansare TM100G pentru intreruptoare ComPacT NSX 100/160, termomagneticee, 100 A, 4 poli 4d
Documente
Specificatii
| Model/type | |
| Type of motor protection | Thermal/magnetic release |
| With ground fault protection function | No |
| Electrical | |
| Rated control supply voltage AC 50 Hz | - |
| Number of poles | 4 |
| Rated control supply voltage AC 60 Hz | - |
| Rated control supply voltage DC | - |
| Voltage type for actuating | Self powered |
| End value adjustment range undelayed short-circuit release | 320 A |
| Overload release current setting | 70 A |
| Rated permanent current Iu | 100 A |
| Setting/control | |
| Initial value of the undelayed short-circuit release - setting range | 320 A |
| Other | |
| Short-circuit release function | Undelayed |
| Package 1 | |
| volume | 2560 cm3 |
| weight | 1,2 kg |
| length | 16 cm |
| width | 10 cm |
| qmax | 1 |
| qmin | 1 |
| um | C62 |
| gtin | 3606482000728 |
| Package 2 | |
| volume | 36000 cm3 |
| weight | 10,02 kg |
| length | 40 cm |
| width | 30 cm |
| qmax | 8 |
| qmin | 8 |
| um | CT |
| gtin | 13606482000725 |
| Package 3 | |
| volume | 432000 cm3 |
| weight | 92,16 kg |
| length | 120 cm |
| width | 80 cm |
| qmax | 64 |
| qmin | 64 |
| um | PF |
