Descriere
Unitate de declansare TM250G pentru intreruptoare ComPacT NSX 250, termomagnetice, 250 A, 4 poli 4d
Documente
Specificatii
| Model/type | |
| Type of motor protection | Thermal/magnetic release |
| With ground fault protection function | No |
| Electrical | |
| Rated control supply voltage AC 50 Hz | - |
| Number of poles | 4 |
| Rated control supply voltage AC 60 Hz | - |
| Rated control supply voltage DC | - |
| Voltage type for actuating | Self powered |
| End value adjustment range undelayed short-circuit release | 520 A |
| Overload release current setting | 175 A |
| Rated permanent current Iu | 250 A |
| Setting/control | |
| Initial value of the undelayed short-circuit release - setting range | 520 A |
| Other | |
| Short-circuit release function | Undelayed |
| Package 1 | |
| volume | 2560 cm3 |
| weight | 794 g |
| length | 16 cm |
| width | 10 cm |
| qmax | 1 |
| qmin | 1 |
| um | C62 |
| gtin | 3606482000766 |
| Package 2 | |
| volume | 39360 cm3 |
| weight | 25408 g |
| length | 41 cm |
| width | 30 cm |
| qmax | 32 |
| qmin | 32 |
| um | CT |
| gtin | 43606482000764 |
| Package 3 | |
| volume | 1440000 cm3 |
| weight | 307200 g |
| length | 120 cm |
| width | 80 cm |
| qmax | 384 |
| qmin | 384 |
| um | PF |
