LV HRC FUSE ELEMENT, NH3, IN: 630 A, AM, UN AC: 690V, UN DC: 440 V, FRONT INDICATOR, LIVE GRIP LUGS
Cod produs: 3ND1372
Descriere
LV HRC fuse element, NH3, In: 630 A, aM, Un AC: 690 V, Un DC: 440 V, Front indicator, live grip lugs LV HRC fuse link SENTRON 3ND for switching device protection in motor circuits. 3ND fuses provide effective protection against short-circuit and are especially suitable for use in motor circuits due to their slow switch-off characteristic. The 3ND LV HRC fuse links are available from 6 A to 630 A in the sizes 000, 00, 0, 1, 2 and 3. SENTRON circuit protection devices - The safe choice. Now made smarter.
Alte coduri:
upc: 754554264356
upc: 754554264356
Documente
Specificatii
| Electrical | |
| Rated voltage AC | 690 |
| Power loss at rated current | 50 |
| Voltage type | AC |
| Rated voltage DC | - |
| Fuse construction type according to IEC 60269 | - |
| Rated current | 630 |
| Model/type | |
| Type of fuse status indicator | Top fuse status indicator |
| Other | |
| Utilization category according to IEC 60269 | - |
| Performance | |
| Rated switching capacity AC | - |
| Rated switching capacity DC | - |
| Options | |
| Insulated metal gripping lugs (IMGL) | No |
| Package 1 | |
| weight | 1,053 |
| length | 0,232 |
| width | 0,162 |
| qmax | 3 |
| qmin | 3 |
| um | PA |
| gtin | 4001869020211 |
