Specificatii
| Model/type | |
| With hinged lid | No |
| Number of device inserts horizontal | 5 |
| Number of device inserts vertical | 1 |
| Number of switch inserts | 10 |
| Number of modules vertical (module system) | 5 |
| Number of modules horizontal (module system) | 10 |
| Number of units | 5 |
| Material | |
| Surface protection | Untreated |
| Surface finishing | Glossy |
| Material | Plastic |
| Halogen free | Yes |
| Material quality | Thermoplastic |
| Mounting/installation | |
| Mounting direction | Horizontal and vertical |
| With mounting grid | No |
| Suitable for built-in installation | No |
| Type of fastening | Engage (snap) |
| Flush-mounted installation | Yes |
| Suitable for wall duct | No |
| Application | |
| Suitable for subfloor installation duct box | No |
| Colour | |
| RAL-number (similar) | 9003 |
| Transparent | No |
| Colour | White |
| Measurements | |
| Built-in height | - |
| Height | 85 mm |
| Diameter bore hole (opening) | 65 mm |
| Width | 369 mm |
| Built-in width | - |
| Depth | 10 mm |
| Protection | |
| Degree of protection (IP) | IP21 |
| Options | |
| Label space/information surface | No |
| Anti-bacterial treatment | No |
| Other | |
| Impact strength | IK04 |
| Package 1 | |
| volume | 314,5 cm3 |
| weight | 54 g |
| length | 37 cm |
| width | 8,5 cm |
| qmax | 1 |
| qmin | 1 |
| um | C62 |
| gtin | 3606489452483 |
| Package 2 | |
| volume | 2721,75 cm3 |
| weight | 344 g |
| length | 38,2 cm |
| width | 9,5 cm |
| qmax | 5 |
| qmin | 5 |
| um | BX |
| gtin | 13606489452480 |
| Package 3 | |
| volume | 72000 cm3 |
| weight | 8,023 kg |
| length | 60 cm |
| width | 40 cm |
| qmax | 105 |
| qmin | 105 |
| um | CT |
| gtin | 43606489452481 |
| Package 4 | |
| weight | 38,444 kg |
| length | 60 cm |
| width | 80 cm |
| qmax | 420 |
| qmin | 420 |
| um | PF |
